In modern engineering construction, the portable horizontal drilling machine has become an ideal choice for laying underground pipelines and cables with its high efficiency and flexibility. It can not only complete the crossing operation without damaging the ground but also greatly reduce the construction cost and improve the efficiency of the project. This article will introduce the parameters, structure, advantages, and price of a Portable Horizontal Drilling Machine in detail to help you better understand this equipment.
Portable horizontal drilling machine parameters
The core parameters of HDD directional drilling include:
| Model | YG200 |
| Main engine part | 48kw 65HP |
| Host width | 1.6m |
| Host length | 3.8m |
| Host height | 1.8m |
| Travel system | remote control, crawler walking |
| Ground drive system | 2KM/hour |
| maximum working distance | 200 Meter |
| Drill pipe diameter | ≤500mm |
| Incidence angle | 10-22 degrees |
| Departure angle | 20 degrees |
| Host weight | 2.3t |
| Water injection system | three-cylinder mud pump |
| Pilot bit | bit diameter 100mm |
| Drill pipe length | 2 meters |
| Climbing ability | 35 degrees |
| Transfer case | 8tons |
| Reducer protection head | 2 |
| Ground Anchor | 2 |
| Reducer protection head | 2 |
| Ground Anchor | 2 |
HDD directional drilling structure
The Portable Horizontal Drilling Machine is mainly composed of the following parts:
- Power unit: Provides the power required for the operation of the equipment.
- Drill rod and drill bit: Responsible for drilling operations, drill rods and drill bits of different materials can be selected according to different geological conditions.
- Control system: Including navigation system and operation interface, to achieve precise positioning and path planning.
- Auxiliary equipment: such as mud pump, used to circulate mud, cool the drill bit, and discharge drill cuttings.
- In addition, the equipment is equipped with a portable design that is easy to transport and install, allowing the Portable Horizontal Drilling Machine to be quickly deployed at various construction sites.
5 Advantages of portable horizontal drilling machine
The HDD directional drilling has the following significant advantages:
- Efficient construction: Compared with traditional excavation methods, it greatly shortens the construction period and reduces costs.
- Accurate positioning: Through advanced control systems, accurate drilling is achieved to avoid damage to the surrounding environment.
- Wide range of applications: Suitable for a variety of terrains such as cities, villages, and mountainous areas, and can be used to lay power, communication, water supply, gas, and other pipelines.
- Environmental protection and energy saving: Environmentally friendly materials and energy-saving designs are used to reduce noise and emissions during construction.
- Compared with rotary drilling rigs and water well drilling rigs, the Portable Horizontal Drilling Machine has significant advantages in crossing complex terrains and laying long-distance pipelines.
Horizontal drilling machine price
The price of the Portable Horizontal Drilling Machine varies depending on the model, configuration, and brand. Generally speaking, entry-level equipment is more affordable and suitable for small construction projects; while high-end models are equipped with more advanced technologies and are relatively expensive, but can greatly improve construction efficiency and quality.
For specific prices, it is recommended to consult professional suppliers to obtain the most accurate quotes and customized solutions. At the same time, when purchasing equipment, you must also consider the costs of after-sales service, repairs, and maintenance to ensure that the equipment remains in the best condition during long-term use.
