The mini road roller is important equipment in compaction operations. It is small in size and compact in structure, but contains huge energy. With the improvement of the refinement of construction, it has developed to meet the compaction needs of special scenes. It can complete many tasks that large machinery cannot reach. It can easily shuttle between narrow alleys, courtyard corners, sidewalks, and other areas. YG is a trustworthy construction machinery manufacturer. Click to get a high-quality and low-cost roller quotation!
Mini road roller parameter
| Model | YG-600S | YG-880 | YG-850 | YG-880 |
| Power | 5.5HP | 25HP/20HP | 6.0HP | 25HP/20HP |
| Walk Speed | 2.4km/h | 0-5KM/H | 0-4km/h | 0-5KM/H |
| Climbing Capacity | 25% | 30% | 30% | 30% |
| Static Linear Load | 45n/cm | 45n/cm | 45n/cm | 45n/cm |
| Exciting Force | 20KN | 50KN | 20KN | 50KN |
| Vibration Frequency | 70HZ | 70HZ | 70HZ | 70HZ |
| Drive | Hydraulic Drive | Hydraulic Drive | Hydraulic Drive | Hydraulic Drive |
| Water Tank | 15L | 15L | 15L | 15L |
| Hydraulic Oil Tank | 3.6L | 19L | 3.6L | 19L |
| Engine Model | HONDA GX160 | GX390 | HONDA GX270 | GX390 |
| Steel Wheel Size | 426x600mm | 800x850mm | 580x700mm | 800x850mm |
| Package Size | 1050x900x1200mm | 2100*1000*1650 mm | 1550x900x1200mm | 2100*1000*1650 mm |
| Weight | 330kg | 1000kg | 750kg | 1000kg |
Types of small rollers-YG
From the perspective of structure, mini road rollers are mainly divided into single steel wheel and double steel wheel rollers. In terms of function, there are semi-hydraulic vibratory rollers and fully hydraulic vibratory rollers. According to the tonnage, different specifications, such as 2-2.5 tons and 3-3.5 tons, are common. From the perspective of name, there are also small hand-held vibratory rollers. Its engine is divided into a diesel engine and a gasoline engine, which can meet the power requirements of different scenes.
1. Walk-behind roller
The walk-behind roller is a small compacting machine that requires the operator to hold the operating handle to control its operation. This type of roller is small in size and flexible in turning. It can easily carry out compaction operations in narrow spaces, such as sidewalks, around flower beds, and in small parking lots. Moreover, it is easy to operate and affordable and is widely favored by small engineering construction teams, providing an economical and practical compaction solution for small construction projects.
2. Walk-behind vibratory roller
The walk-behind vibrating roller is based on the ordinary walk-behind roller, and a vibration device is added. During operation, the vibration device will cause the roller to vibrate at a high frequency, and with the help of the vibration impact force and the roller’s gravity, the ground is compacted, greatly improving the compaction effect and work efficiency. The roller has strong maneuverability, a small turning radius, and can operate flexibly in a small area. It is often used for road repairs and compaction of small squares, courtyards, and other venues.
3. Tandem roller for sale
Double drum rollers have steel wheels at the front and rear, and some have vibration functions. When working, the front and rear steel wheels compact the road surface in coordination so that the road surface is evenly stressed and the compaction flatness can be effectively guaranteed. Due to the double steel wheel design, it has good stability during the compaction process and is not prone to deviation. In asphalt pavement construction, double steel wheel rollers are the main equipment, often used in projects with strict requirements on road surface flatness, such as high-grade highways and urban trunk roads.
4. Single drum vibratory roller
The front steel wheel of the single steel wheel vibratory roller is responsible for vibration compaction, and the rear tire provides driving force and maintains balance. It has a strong excitation force and large compaction depth. With the impact force generated by vibration, it can effectively compact deep soil and various basic materials. This type of roller is suitable for the compaction of large areas and thick paving layers, such as large highway roadbeds, embankment construction, and industrial site filling compaction.
Hot-sale road roller application
- Highway municipal maintenance: In the layered compaction of the cement stabilization layer in replacement construction, as well as the compaction of asphalt concrete at the edges and corners of ditches and wells, mini road rollers can show their skills. In highway construction, when backfilling structures such as culverts, passages, and abutments, small rollers can operate flexibly in areas where large rollers cannot be used.
- Landscape construction: Municipal garden landscapes, residential community landscapes, golf course construction, and sidewalk pavement paving and compaction, small rollers can complete the task efficiently with their compact size.
- Other narrow areas: As long as the construction area is narrow and the weight of the compaction equipment is sensitive, small rollers can complete the compaction work flexibly and efficiently.
Road roller working principle
Small rollers work mainly based on the compaction principle. The rollers repeatedly roll the fill soil and pavement materials to increase the density of the working surface and improve the structural strength and rigidity. Like a vibrating small roller, it works by relying on a vibrating wheel. The eccentric shaft in the vibrating wheel rotates at high speed under the drive of the vibrating motor to generate vibration, which is transmitted to the compacting roller, reducing the friction between the roller and the roadbed and pavement. Using the principle of alternating shear strain, the pores of the soil particles become smaller and are arranged more closely, thereby improving the compactness of the roadbed and pavement.
4 Advantages of mini road roller for sale
- Strong mobility: small size, small turning radius, can operate flexibly in narrow spaces, and easily reach places that large rollers cannot reach.
- High work efficiency: Although it is small in size, it has strong working power and fast compaction speed, which can effectively shorten the construction period.
- Easy to transport: compact structure, light weight, easy to transport, and can be quickly transferred to different construction sites.
- Simple operation: The operation control system is designed to be user-friendly, easy for operators to use, and reduces labor costs and operating difficulties.
Why choose YG’s pavement roller?
YG mini road rollers are made of high-quality materials, and the key components are of reliable quality. After a strict quality inspection, they have stable performance, long service life, and reduced maintenance costs and downtime. Adopt advanced technologies, such as an efficient vibration system, strong excitation force, and good compaction effect. The roller has a precise hydraulic control system, which is more flexible and stable to operate. YG provides mini road rollers of various models and specifications. The engine type, tonnage, function, etc., can be selected as needed to meet the needs of different construction projects. We also produce other related road machinery and equipment, such as marking machines, line removers, and pavers. Click to get the factory price of the roller!
