Cold spray road marking machine, as a special equipment for road marking, adopts normal temperature cold spray technology to spray liquid paint evenly onto the road surface to form clear and standardized traffic marking lines. It is also called a road marking machine for sale, cold paint making machines, etc. It has various types, from small handheld equipment to large vehicle-mounted equipment, which can meet the needs of road marking projects of different scales.
Cold paint road marking machine parameter
YG-8S Single-gun road marking machine
| Model | YG-8S |
| Motor power | 5.5hp Honda gasoline engine |
| Plunger pump | Electronic reversing |
| Number of spraying gun | Single gun |
| Work mode | Hydraulic |
| Pressure | 8-12Mpa |
| Unloading flow | 4.8L/min |
| Spray width | 100-300mm |
| Spray thickness | 0.2-0.4mm |
| Size | 1600*800*1200mm |
| Weight | 120kg |
YG-8d double-gun cold paint road marking machine
| Model | YG-8D |
| Motor power | 5.5hp Honda gasoline engine |
| Plunger pump | Automatic Reciprocating Commutation |
| Number of spraying guns | Double gun |
| Work mode | Hydraulic |
| Pressure | 8-12Mpa |
| Unloading flow | 8L/min |
| Spray width | 100-450mm |
| Spray thickness | 0.2-0.4mm |
| Size | 1600*800*1200mm |
| Weight | 120kg |
Application of cold paint road marking machine
The cold spray road marking machine is widely used and suitable for various road scenes.
- In municipal road construction, it can draw conventional markings such as lane lines, center lines, zebra crossings, etc., to ensure the orderly passage of vehicles and pedestrians.
- During the construction of parking lots, the cold spray road marking machine can be used to clearly divide parking space lines and channel lines and improve the space utilization rate of parking lots.
- In addition, it can also play an important role in community roads, school playgrounds, and other places to create a safe and orderly traffic environment.
Working principle of cold spray road marking machine
The cold spray road marking machine pressurizes the paint through a high-pressure pump and sprays it onto the road surface through the nozzle. The equipment is equipped with a precise flow control system, which can accurately adjust the spray volume of the paint according to construction requirements. During the spraying process, the spray gun moves along the set path, and the paint quickly adheres to the road surface and solidifies to form a neat marking line. Some advanced cold spray road marking machines are also equipped with an automatic guide system to ensure the straightness and accuracy of the marking.
Advantages of cold paint road marking machine
- The cold spray road marking machine is easy to operate, and the operator can become proficient after a short training.
- It has high construction efficiency. Compared with traditional manual marking, it can greatly shorten construction time and reduce labor costs.
- The marking quality is stable, and the sprayed marking lines are uniform and clear, with strong adhesion, good wear resistance and weather resistance, and long service life.
- Moreover, cold spray technology does not require heating of paint, saves energy, and is more environmentally friendly.
Why buy a cold spray road marking machine?
- Purchasing a cold spray road marking machine can significantly improve the quality and efficiency of road marking operations.
- For road construction companies, owning a cold spray road marking machine can not only undertake more projects but also improve the competitiveness of the company.
- For municipal departments, it can ensure the timely update and maintenance of road markings and improve the management level of urban roads.
- In addition, using a cold spray road marking machine for marking operations can reduce the impact on traffic and reduce construction risks.
High-quality road marking machine for sale manufacturer- YG
YG focuses on the research and development, and production of cold spray road marking machines. It is a well-recognized manufacturer in the industry, and a large number of cold paint road marking machines have entered the market from here. YG’s products have excellent performance, advanced technology, and stable quality, which can meet the needs of different customers. In terms of price, YG fully considers the cost requirements of customers and provides cost-effective products, allowing customers to obtain high-quality equipment at a reasonable price. At the same time, YG also provides comprehensive after-sales service, and the professional technical team provides technical support and maintenance services to customers at any time so that customers have no worries. If you are looking for a reliable cold spray road marking machine, choose YG!
