The cement concrete block making machine is the core equipment of the modern construction industry, used for the efficient production of cement bricks, hollow blocks, and various special-shaped building materials. Through automation technology, it can accurately shape sand, cement, and water after mixing, greatly improving production efficiency and product strength. As an industry benchmark, the model developed by YG also supports linkage with equipment such as concrete delivery pumps and mortar sprayers, forming an integrated solution from raw material processing to wall construction, meeting the needs of various scenarios such as municipal engineering and industrial plants.
Cement concrete block making machine parameters
YG brand Cement Concrete Block Making Machine has excellent parameters
| Block Name | Size (L*W*H)mm | Molding Cycle | QTY/Mould | QTY/hour | Qty/8hr |
| Hollow block | 400*200*200 | 15-20s | 6pcs | 1080-1440pcs | 8640-11520pcs |
| Hollow block | 400*150*200 | 15-20s | 7pcs | 1260-1680pcs | 10080-13440pcs |
| Hollow block | 400*100*200 | 15-20s | 11pcs | 1980-3640pcs | 15840-21120pcs |
| Porous block | 240*115*90 | 15-20s | 15pcs | 2700-3600pcs | 21600-28800pcs |
| Standard brick | 240*115*53 | 15-17s | 30pcs | 6300-7200pcs | 50400-57600pcs |
| Paver | 225*112.5*60 | 20-25s | 15pcs | 2160-2700pcs | 17280-21600pcs |
Concrete block molding machine working principle
The concrete block molding machine completes brick making through four steps of “batching-conveying-compacting-demolding”:
- Raw material mixing: The automatic weighing system mixes cement, aggregate, and water in proportion;
- Mold filling: The conveyor belt feeds the mixture into the vibrating mold, and high-frequency vibration removes bubbles;
- Hydraulic molding: The hydraulic cylinder applies 15-25MPa pressure to form high-density bricks;
- Intelligent demolding: The robotic arm transfers the finished product to the maintenance area, and the mold is automatically cleaned and enters the next cycle.
- YG equipment is also equipped with a fault warning system to monitor bearing wear and hydraulic oil status in real time to minimize the risk of downtime.
Block brick making machine price analysis
The price of a brick molding machine is greatly affected by production capacity, degree of automation, and brand. Small and medium-sized semi-automatic equipment has a lower cost but requires more manual intervention; high-end fully automatic models have higher initial investment but can quickly recover costs through 24-hour continuous production and low failure rate. YG’s Cement Concrete Block Making Machine is known for its high-cost performance – it uses wear-resistant alloy steel molds, has a service life of more than 100,000 times, and consumes 15% less energy than similar products.
YG’s block brick making machine
YG has been deeply involved in the field of brick-making machinery for 30 years. Its Concrete Block Molding Machine has passed ISO9001 certification and has been recognized by customers in more than 50 countries around the world. Core advantages include:
- Ultra-long durability: key components are made of imported materials from Germany, and the whole machine is designed to last for more than 15 years;
- Intelligent service: remote debugging and operation training are provided, and a localized spare parts library is established to solve faults within 48 hours;
- Scenario adaptation: The equipment can be customized and upgraded, such as adding an insulation brick production line or connecting a mortar sprayer to achieve automated wall construction.
Cases have proved that after a building materials factory in the Philippines purchased YG equipment, its production capacity increased by 200%, saving more than 120,000 US dollars in labor costs per year. Consult now to get exclusive brick-making solutions!
