The anchor drill machine, as the name implies, is a highly efficient mechanical equipment specially used for anchor construction in geotechnical engineering. It drills deep into the ground by rotating the drill rod and drill bit and then installs anchors to enhance the stability of the rock and soil. The ground anchor drilling rig is widely used in slope support, tunnel reinforcement, foundation pit enclosure, and other fields and is an indispensable and important tool for modern geotechnical engineering construction.
Anchor drill machine parameters
A high-performance anchor drill machine may be equipped with a powerful hydraulic system, supporting a maximum drilling diameter of 200 mm and having excellent terrain adaptability.
| Machine Parameters | |||
| Weight | 6T | Drilling diameter | 150-250mm |
| Drilling depth | 130-170m | Drill pipe diameter | 73,89,102,114mm |
| Shipping size | 5400*2100*2000mm | Vertical working size | 3600*2500*5600mm |
| Power Configuration | |||
| Electric motor | Power 55kw+18.5kw | ||
| Powerhead | |||
| Rated output torque | 7500Nm | ||
| Rated speed | 10,20,30,35,40,60,65,70,85,130,170rpm | ||
| Propeller | |||
| Boost speed | 0-5 Adjustable,7,23,30m/min | Feed speed | 0-10 Adjustable,14,46,59m/min |
| Rated lifting force | 70kN | Rated feed force | 36kN |
| Feed process | 3400mm | Slip process | 900mm |
| Drilling rig angle | |||
| Drilling angle | 0-90° | Climbing angle | 25° |
Why do people use a hydraulic crawler drill?
- The main reason for using anchor drill machines is their high efficiency, safety, and economy.
- Compared with traditional manual excavation or simple mechanical operations, anchor drill machines can greatly improve construction efficiency and reduce labor costs.
- At the same time, precise drilling control and strong anchoring ability effectively improve the safety factor of engineering structures.
- In projects with complex geological conditions and high requirements for construction precision, the hydraulic crawler drill has shown incomparable advantages.
Specific Applications of Anchor Drill Machine
- Slope stabilization: Anchoring technology is used to reinforce slopes along mountain roads and railways to prevent landslides.
- Tunnel engineering: During tunnel excavation, anchor rods are used to support the top and side walls of the tunnel to ensure construction safety.
- Deep foundation pit support: In the foundation construction of urban high-rise buildings, anchor rods are used to stabilize the side walls of the foundation pit and protect the surrounding environment.
- Water conservancy and hydropower: Slope and dam reinforcement of water conservancy facilities such as dams and reservoirs, as well as support of underground powerhouses of hydropower stations.
YG crawler drill machine price
YG anchor drill machine enjoys a high reputation in the global market for its excellent performance, high quality, and low price. We use advanced hydraulic crawler drill technology to ensure that the equipment can still operate stably and efficiently in complex environments. YG drill rigs not only have fast drilling speed and high precision but are also easy to maintain and have a long service life. More importantly, we are committed to providing the most competitive crawler drill machine price to ensure that every customer can enjoy a cost-effective solution. Whether it is a large-scale engineering project or a small maintenance operation, YG anchor drill rigs can be perfectly adapted, covering the global market and meeting diverse needs.
