YG recently successfully delivered a 350-meter water well drilling rig solution to a Guatemalan customer to help with local water resources development. Guatemala in Central America has abundant groundwater but complex geology. The traditional local well drilling method is inefficient and costly, and professional equipment is urgently needed. YG’s water well drilling machine for sale meets customer needs and has become a “well drilling artifact” for local engineering teams.
Water well drilling machine for sale parameters
| Model | YG-180 | YG–200 | YG–300 | YG–300A | YG–400 | YG–600 |
| Drilling hole diameter | 140-254mm | 140-305mm | 140-325mm | 140-325mm | 140-350mm | 140-350mm |
| Drilling depth | 180m | 200m | 300m | 300m | 400m | 600m |
| One-time advance length | 3.4m | 3.4m | 6.6m | 3.4m | 6.6m | 6.6m |
| Walking speed | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h |
| Climbing angles (Max.) | 30 | 30 | 30 | 30 | 30 | 30 |
| Equipped capacitor | 55kw | 65-70kw | 84kw | 75.8kw | 92kw | 115kw |
| Using air pressure | 1.7-2.5mpa | 1.7-3.0mpa | 1.7-3.3mpa | 1.7-3.0mpa | 1.7-3.5mpa | 1.7-3.5mpa |
| Air consumption | 17-31m³/min | 17-30m³/min | 17-35m³/min | 17-35m³/min | 17-35m³/min | 17-35m³/min |
| Drill pipe length | 1.5m, 2.0m, 3.0m | 1.5m, 2.0m, 3.0m | 1.5m, 2.0m, 3.0m,6.0m | 1.5m, 2.0m, 3.0m | 1.5m, 2.0m, 3.0m,6.0m | 1.5m, 2.0m, 3.0m,6.0m |
| Drill pipe diameter | 76mm, 89mm | 76mm, 89mm | 89mm, 102mm | 76mm, 89mm, 102mm | 89mm,102mm,108mm | 102mm,108mm,114mm |
| Rig lifting force | 15t | 12t | 20t | 16t | 22t | 28t |
| Swing speed | 45-65rpm | 45-70rpm | 45–115rpm | 40–70rpm | 45-115rpm | 45–115rpm |
| Swing torque | 3200-4600(N.m) | 3500-4800(N.m) | 6200-8500(N.m) | 5700-7500(N.m) | 6500-9000(N.m) | 8500-11000(N.m) |
| Dimension | 3800*1500*2200mm | 4000*1750*2450mm | 5900*2000*2850mm | 4100*1950*2600mm | 5900*2100*2850mm | 6000*2200*2850mm |
| Weight | 4500kg | 5800kg | 9000kg | 7000kg | 10000kg | 12000kg |
Guatemala customer feedback
“It used to take 5 days to drill a 100-meter well with old equipment. Now, with YG water well drilling equipment, a deep water well can be drilled in 3 days!” Alfonso, head of the Guatemala Engineering Company, gave a thumbs up, “The matching air compressor is super powerful, the mud pump discharges quickly, and the drilling tools are almost not worn!”
YG customized water drilling equipment solution
For the geology of the water well that the Guatemalan customer needs to drill, YG provides a full set of solutions:
350-meter water drilling equipment + air compressor + mud pump + drilling tools.
- Air compressor: 15m³/min exhaust volume to ensure the bottom of the hole is clean.
- Mud pump: 200m head, no pressure to deal with deep well discharge.
- Special drilling tools: tungsten steel alloy drill bit + spiral blade, anti-drilling design is super practical.
Application of borehole drilling rig by customers
- Agricultural irrigation: Using YG drilling rigs to drill 200-meter deep wells in farmland, irrigation costs dropped by 70%.
- Community water supply: Remote village project, 4 150-meter wells were completed in a single day, and villagers drank clean water.
- Mining exploration: A gold mining company purchased 3 drilling rigs to explore groundwater resources to help mining.
“The YG team is so reliable!” Alfonso said, “They sent engineers to the site for debugging and trained us to operate water drilling rigs. Now the number of orders has doubled, and colleagues are asking where to buy the equipment!”
Water well drilling rig for sale supplier- YG
YG has become a recognized high-quality water well drilling rig supplier in the Guatemalan market with its strong technical strength and customized services. Given the complex local geology, YG provides a full solution of 350-meter drilling rigs + air compressors + mud pumps, and the efficiency of special drilling tools penetrating rocks is increased by 60%. Customer Alfonso praised: “The YG team not only sells equipment but also provides operation training and 24-hour technical support!” From farm irrigation to mining exploration, YG drilling rigs help customers reduce costs and increase efficiency with stable performance.
Click to consult YG water well drilling machine for sale to get a detailed quote!
