Portable loading dock ramps sold to Brazil

Brazil’s e-commerce is growing at an annual rate of over 20%, but the logistics infrastructure is lagging, especially in Sao Paulo, Rio de Janeiro, and other cities where warehouse centers are facing the following pain points:

  1. Limited space: the height of loading and unloading platforms in old warehouses does not match that of standard trucks;
  2. High labor costs: traditional hitches rely on human labor for handling, with high accident rates;
  3. Climatic challenges: Humidity and high temperatures during the rainy season accelerate equipment corrosion.
    Therefore, Brazilian customers prefer to purchase corrosion-resistant, adjustable, and high load-bearing Portable Loading Docks to cope with the changing operating environment.

Free Quote Now

Portable Loading Dock Parameters

ItemYGY6-0.9YGY8-0.9YGY10-0.9YGY12-0.9YGY15-0.9
Main Bean Size(mm)160*80*4160*80*5160*80*4200*100*5160*80*4
Auxiliary Beam Size(mm)100*50*3100*50*4100*60*4120*60*5120*80*5
Rated Load(kg)60008000100001200015000
Variable Range(mm)1100-18001100-18001100-18001100-18001100-1800
Bridge Length(mm)1140011400114001140011400
Bridge Width20002000200020002000
Solid Tire600-9600-9600-9700-9700-9
Shelf10#10#10#12#14#
Tongue Plate1414162020
Machine Quality24002600280035005000

Free Quote Now

YG hitch axle models purchased by Brazilian enterprises

For the Brazilian market, YG has launched the “Tropical Special Edition” hitch axle. The core configuration includes:

  1. Rust-proof upgrade: double-layer hot-dip galvanized + anticorrosion coating, adapting to the high-humidity environment in the rainy season;
  2. Flexible height: hydraulic adjustment range of 0.5-1.6 meters, adapting to the common Brazilian truck size;
  3. Super load-bearing: dynamic load of 4 tons, can pass 2 forklifts at the same time;
  4. Rapid deployment: 10 minutes to complete the assembly, without the need for specialized tools.
    Typical Customer Choice: A logistics company in Sao Paulo purchased 8 sets of YG-2000H model at one time for handling 3,000 e-commerce parcels per day.

Efficient loading and unloading solutions provided by YG for customers

1. Project Background
In 2023, a port operator in Rio de Janeiro experienced a surge in container demurrage costs due to the inefficiency of traditional hitches (trucks waited an average of 2 hours).

2. YG Solution

2.1 Provision of 4 extended hitch bridges (6m deck) with a load capacity of up to 8 tons;

2.2 Customized non-slip textured bridge deck to cope with slippery road surface in rainy season;

2.3 Equipped with Portuguese operation manual and on-site training.

Free Quote Now

    Why customers buy YG’s hitch bridge

    1. Excellent material: the main beam is made of Q345B manganese steel, with a long service life of 15 years (average 8 years for similar products in Brazil);
    2. Intelligent safety: automatic alarm in case of tilting, anti-skid locking device to reduce the risk of accidents;
    3. Energy saving and environmental protection: the energy consumption of the hydraulic system is 30% lower than traditional models, which is in line with Brazil’s green logistics policy;
    4. Flexible Expansion: It can be retrofitted with a roof, telescopic rail, and other modules to meet future business upgrading needs.
