Recently, YG successfully delivered a batch of high-performance excavator attachment plate compactors, namely hydraulic compactors, to customers in the UAE. This batch of equipment is mainly used to enhance the foundation compaction capacity in infrastructure construction in the UAE. Customers highly recognize the product quality and technical strength of YG and look forward to improving construction efficiency and quality through this batch of equipment.
Excavator hydraulic compactor parameters
The sturdy design and efficient performance of the excavator vibrating plate (Excavator Plate) and the vibrating plate compactor (Vibrating Plate for Excavator) make it an ideal choice for customers in the UAE.
| Model | HWX03 | HWX06 | HWX08 | HWX10 |
| Suitable for excavators (ton) | 4-9 | 11-16 | 17-23 | 23-30 |
| Strike force (ton) | 4 | 6.5 | 15 | 15 |
| Maximum number of vibrations (rpm) | 2000 | 2000 | 2000 | 2000 |
| Oil consumption (l/min) | 45~75 | 85~105 | 120~170 | 120~170 |
| Pressure (kg/cm2) | 100~130 | 100~130 | 150~200 | 150~200 |
| Weight (kg) | 300 | 500 | 900 | 950 |
| Strike area ((L*W*T, mm) | 900x550x25 | 1160x700x28 | 1350x900x30 | 1350x900x30 |
| Overall height(mm) | 760 | 920 | 1060 | 1110 |
| Overall width(mm) | 550 | 700 | 900 | 900 |
Reasons for purchasing an excavator plate
The client is a well-known construction company in the UAE, focusing on the construction of highways, airports, and large infrastructure projects. With the rapid economic development of the UAE region, the construction challenges faced by customers are increasing, especially the requirements for foundation compaction, which are getting higher and higher. To improve construction efficiency and quality, the customer decided to introduce advanced hydraulic compactors (Hydraulic Compactors) to meet the growing construction needs.
Benefits of using the vibrating plate for excavator
After introducing this batch of hydraulic compactors, the client has achieved remarkable results in construction. The efficient compaction capacity of the equipment has greatly shortened the construction period and improved work efficiency. At the same time, the precise control of the excavator plate and the vibrating plate for the excavator ensures the stability and consistency of the construction quality. In addition, the energy-saving and environmentally friendly characteristics of the equipment also meet the environmental protection requirements of the UAE region, winning a good social reputation for the client.
Positive feedback from the hydraulic compactor client
The client is highly satisfied with the hydraulic compactors provided by YG. They believe that this batch of equipment not only has excellent performance but is also easy to operate and maintain. In many constructions, the equipment has performed well and effectively improved the construction quality and efficiency. The client also particularly appreciated YG’s after-sales service, believing that the company provided all-around support during the delivery, installation, and commissioning of the equipment to ensure the smooth operation of the equipment.
