A rebar threading machine was sold to Australia. This machine is commonly used in construction projects. Efficient, stable, and environmentally friendly rebar rolling machine is the favorite of people. YG’s rebar rolling machine has been sold to many countries because of its excellent performance and wide range of applications. Our rebar threading machine price is affordable. Click to get more information!
Rebar Threading Machine Parameters
| Model | YG28-40 | YG28-80 | YG28-150 | YG28-185 | YG28-200 |
| Max rolling pressure | 120KN | 150kn | 150kn | 180kn | 200kn |
| Hydraulic diameter | 5-36MM | 6-42mm | 6-48 | 10-60mm | 14-80mm |
| Rolling wheel diameter | 120-170MM | 120-170mm | 120-170mm | 175-220mm | 175-220mm |
| Max width of rolling wheel | 110MM | 110MM | 110MM | 150mm | 150mm |
| Spindle center distance | 120MM | 120MM | 120MM | 150-300mm | 150-300mm |
| Rolling wheel aperture | 54hole | 54hole | 54hole | 75hole | 75hole |
| Hydraulic power | 4kw | 2.2kw | 2.2kw | 3kw | 5.5kw |
| Main motivation | 4kw | 5.5kw | 7.5kw | 11kw | 11kw |
| Spindle speed | 36-78/min | 36-78/min | 36-78/min | 20-64/min | 20-64/min |
| Spindle tilt angle | ±5° | ±5° | ±5° | ±10° | ±10° |
| Thread length | No limited | No limited | No limited | No limited | No limited |
| Dimensions | 1.4*1.2*1.4m | 1.48*1.33*1.44m | 1.47*1.33*1.44m | 1.78*1.73*1.43m | 1.78*1.73*1.43m |
| Weight | 1100kg | 1700kg | 1800kg | 2000kg | 2600kg |
Advantages Of Thread Rolling Machine For Sale
- Wide applicability: it can process positive and negative threads, applicable to different specifications and materials of steel bars.
- Simple operation: the operation of the machine is simple and easy to understand, and the workers can master the operation skills only after a short training.
- High thread quality: the steel bars processed and molded by the YG steel bar rolling machine have good comprehensive mechanical properties. Tensile strength is increased by 20%-30%, fatigue strength is increased by 40%-60%, and corrosion resistance is increased by 50%-200%.
- Material saving: steel bars can be connected using a wrench or a rebar cold extruder. The connector is a rebar sleeve, no additional welding material is needed, saving material cost.
Why Do Customers Choose The YG Rebar Rolling Machine?
YG is a professional manufacturer of rebar handling equipment. Our rebar rolling machine can finish rolling quickly, which greatly improves construction efficiency and helps to advance the project. The rebar after rolling has higher strength and is more stable and reliable. We will provide perfect after-sales service and technical support to our customers. We also provide steel bar piercing and roughing machines, steel bar straightening and cutting machines, steel bar bending machines, steel bar cold extrusion machines, and so on. If you need to click contact us to get the rebar threading machine price!
