Last month a hydraulic core drilling rig was sold to Guinea. Fully hydraulic core drilling rigs are specialized in resource exploration. Our fully hydraulic core drilling rigs can use rope core drilling technology. This equipment has the performance of high construction efficiency, good construction quality, low accident rate, and strong drilling adaptability. This drilling rig is suitable for geology, metallurgy, coal, petroleum, natural gas, groundwater, and other industries. Click to get the details of fully hydraulic core drilling rig equipment!
Hydraulic Core Drilling Rig Parameters
| Model | YGX-400 | YGX-600 | YGX-800 | YGX-1000 |
| Drilling Depth(M) | 180-400-500 | 200-600-650 | 400-800-1000 | 500-1000-1100 |
| Rated pressure(MPA) | 21 | 21 | 25 | 28 |
| Rated Flow(L/min) | 168 | 192 | 260 | 300 |
| Heat Dissipation Mode | Air cooling+water cooling | |||
| Engine Brand | Yuchai | Yuchai | Yuchai | Cummins |
| Rated power/speed | 78kW/ 2400r/min | 92kW/ 2400r/min | 92kW/ 2400r/min | 154kW/2400r/min |
| Drilling Angle(°) | 0-90 | 45-90 | 45-90 | 45-90 |
| Lifting Force(T) | 12 | 16 | 24 | 30 |
| Feed Force(T) | 6 | 8 | 12 | 15 |
| Hydraulic Mud pump flow | 30-90（L/min） | 30-90（L/min） | 90-180（L/min） | 90-180（L/min） |
| Hydraulic Mud pump power | 4-7(MPA) | 4-7(MPA) | 4-7(MPA) | 4-7(MPA) |
| Dimension | 4000*1900*1800mm | 4000*2000*1800mm | 5500*2100*2000mm | 6000*2200*2400mm |
| Weight | 4.3T | 4.5/5.5T | 6.5T | 7.5T |
Guinea Customer Background
Guinea is one of the countries with rich mineral resources in the African continent. Its territory has a large number of iron ore, bauxite, gold, and other valuable resources. The customer is a drilling rig equipment dealer in Guinea. Recently a customer wants to buy a fully hydraulic core drilling rig. Therefore, the customer searched for this equipment on Google, and after comparison, the customer decided to contact us.
Benefits of Using Core Drilling Machine for Mining
- Increase drilling efficiency. The fully hydraulic drive system ensures that the drill rig can maintain stable power output during operation. Rapid penetration into the rock layer and fast drilling speed.
- High drilling precision. Through the intelligent and precise control system. The hydraulic core drilling rig can accurately control the drilling direction and depth to obtain high-quality core samples.
- Reduced labor intensity. The core drilling rig for mining is an automated operation that reduces the labor intensity of workers and improves the safety of operations.
- Flexible response to complex geology. The fully hydraulic core drilling rig has many functions and adjustable parameters. Therefore, it can smoothly carry out exploration work according to different geological conditions.
Hydraulic Core Drill Related Equipment from YG
YG is a professional manufacturer of hydraulic core drilling rig equipment. We provide related equipment, such as mud pumps and water finders. Combined with these two types of equipment, the core drilling work can be completed more efficiently. We also produce rotary drilling rigs, piling drivers, solar piling rigs, guardrail piling rigs, wireline rope hydraulic core drilling rigs, small excavators, and other equipment. Our fully hydraulic core drilling rig is one of the hot-selling drilling rig equipment and till now we have exported this machine to Guinea, Brazil, the Philippines, Botswana, Nepal, and other countries. We will recommend the right equipment solution for your specific needs. Click contact us to get the latest machine quotation!
